2024 Thermo HyPerforma 250L S.U.B. – 5:1 Jacketed Bioreactor, Load Cells, No Controller – New – Taiwan

Bid Type:—

Location:

Quantity:1

TaxesTo be added at payment

Seller's Terms & Conditions

Core Specifications

Thermo Scientific HyPerforma 5:1 Single-Use Bioreactor – 250L, Jacketed, Scalable, Brand New The HyPerforma 250L Single-Use Bioreactor (S.U.B.) is a GMP-ready, stirred-tank bioreactor system designed to deliver maximum flexibility and scalability for biologics production. Built with a 5:1 turndown ratio, this bioreactor allows operation from 50L to 250L volumes, minimizing seed transfers and reducing disposable use. This unit features a jacketed stainless-steel tank, magnetically coupled agitation, and compatibility with open-architecture or turnkey control systems (e.g., DeltaV, Allen-Bradley, Siemens). It includes ports for multiple probes, dual gas spargers (cross-flow and drilled-hole), and optional accessories for enhanced process control. Specifications

Model: HyPerforma 250L Single-Use Bioreactor
Rated Working Volume: 250 L
Minimum Working Volume: 50 L
Total Volume (liquid + gas): 316 L
Turndown Ratio: 5:1
Impeller: 1 × 3-blade, 20 cm diameter, 45° pitch
Mixing Speed: 30–150 rpm
Mixing Flow: Down-pumping
Drive Motor: 208V AC, 3-phase, 0.25 hp
Tank Jacket Area: 1.3 m² (cooling/heating)
Jacket Flow Rate: 136 L/min @ 3.4 bar
Heat-up Time (5°C–37°C): 1.1 hr (20% vol), 3.4 hr (100% vol)
Overall Dimensions (W × L × H): 121.3 × 121.3 × 214.9 cm
Control Type: External (not included, shared with Unit #145)
Probe Ports: 4 (12 mm Ø × 215–235 mm insertion)
Load Cells: Included
Status: Brand New, Unopened
Year: 2024
Location: Taiwan

Key Features

5:1 turndown ratio reduces BPC usage and seed steps
Open architecture for compatibility with various controllers
Jacketed tank for rapid thermal control
Pre-configured for dual spargers for seed and process culture
Load cells and probe-ready ports included
Shared controller with Unit #145 (controller not included)

Applications Perfect for vaccine production, cell therapies, and large-scale upstream bioprocessing. Ideal for facilities requiring flexibility, sterility, and scalability across R&D to clinical or GMP-grade production. Condition Brand new, factory-sealed. Ready for integration. Shares external controller with another unit (#145). Accessories and controller not included.

Condition

working
